Overview
The TX Mainboard-7 Devkit + TXUL-5010 is the legacy-grade Ka-Ro NXP i.MX 6 UltraLite SIMM-CoM development platform. Single Cortex-A7 at 528 MHz with NEON multimedia and a long-life industrial supply window — pre-mounted on the TX Mainboard-7 carrier. Ideal for cost-sensitive industrial control, legacy Linux applications and long-life designs.
What's in the Box
TX Mainboard-7 Carrier
2× USB host, USB-OTG, Gigabit Ethernet, RS-232/485, CAN, micro-SD, dual TTL/LVDS display headers, audio I²S and a 40-pin extension header.
TXUL-5010 Module
Pre-mounted on the carrier with heat-spreader fitted. Snaps into the DIMM200 socket — swap to any other Ka-Ro TX module. NXP i.MX 6 UltraLite ready out of the box.
Power & Cables
12 V / 3 A power supply (EU + UK + US plugs included), USB-serial debug adapter and cable.
Software & Support
Pre-flashed Yocto-Linux BSP, full schematics, design package, ikoniq engineering support and a 12-month warranty.
TXUL-5010 Module at a Glance
| Specification | TXUL-5010 |
|---|---|
| SoC | NXP i.MX 6 UltraLite (MCIMX6G2) |
| CPU | 1× Cortex-A7 @ 528 MHz |
| Multimedia | NEON SIMD + VFP |
| RAM | 256 MB DDR3 (16-bit) |
| Storage | 128 MB NAND |
| Display | LCD TFT 24bpp |
| Camera | 8-bit Parallel CSI |
| Form Factor | DIMM200 SIMM-CoM (26 mm SO-DIMM) |
| Temperature | -40°C to +85°C (Industrial+) |
TX Mainboard-7 Baseboard Features
Why this Kit?
One Carrier, Every TX Module
The DIMM200 socket on TX Mainboard-7 accepts every Ka-Ro TX module — i.MX 93, i.MX 91, i.MX 8M Plus, RZ/G2L, STM32MP and more. Validate one application across the entire family on the same hardware.
Headless & Display Ready
Boots straight to a serial console out of the box. Add the optional 10.1″ touch display via the Mainboard-7 LVDS connector when you need an HMI.
Production-Grade Connectivity
Industrial-grade RS-232/485, CAN, Gigabit Ethernet, USB host/OTG and audio — exercise the full peripheral set you will use in production.
Made in Germany
TX Mainboard-7 and TX-family modules are designed and manufactured by Ka-Ro Electronics. 12-month warranty and 10+ year availability commitment.
Software & Support
Yocto-Linux BSP
Reference image based on Yocto kirkstone / scarthgap. Boots straight to a Linux console out of the box.
Mainline U-Boot + Linux Kernel
Long-term-supported sources, including Ka-Ro device-tree overlays and module-specific patches.
Schematics & Design Package
Full carrier-board schematics, gerbers and BOM available on request to support your own carrier design.
Documentation
Datasheets for the TXUL-5010 module and the TX Mainboard-7 baseboard.
